Plain Weave Stainless Steel Woven Wire Mesh Screen Square Hole Smooth And Bright Surface

Brand Name : BS•EVER

Model Number : Plain weave

Certification : ISO 9001:2015

Place of Origin : China

MOQ : 1 roll

Price : negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 1000 rolls per week

Delivery Time : common spcification can delivery immediately

Packaging Details : paper/plastic packing/ carton packing/ wooden case/ according to customers' request

Material : SUS201/202/310/304/316/316L...

Hole shape : Square

Weaving type : plain weave

Mesh No. : 1-635mesh/inches

Color : bright

Usage : Screen, Filteration,Printing

Other name : stainless steel wire mesh/stainless steel mesh screen

Sample : small piece of sample for free

Surface : Flat, Smooth and bright

Contact Now

Plain weave stainless steel wire mesh

Details sheet:

Material Stainless steel/brass ,nickel /titanium /monel molybdenum /tungsten /tantalum /inconel/nichrome etc
Grade SUS 201, 202, 304, ,304L,316, 316L, 430, etc.
Weaving type Plain weave
Hole style Square
Width 500 mm-3000 mm(1.5'-10') Common is 3-6'
Length 0.5 meter-50 meters(1.5'-164') Common is 15m,20m,25m,30M
Mesh count 1-635 mesh
Thread diameter 0.008-0.08inch (0.0203-2.03mm)
Aperture/openning 0.0008-0.92inch(0.0203-23.37mm)
Technique Woven
Type in rolls/ in pieces / made into arts and crafts
Surface Flat ,smooth and bright
Note: customized specfication is also ok and highly welcomed

Plain Weave

It is also called tabby weave, linen weav or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple crisscross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.

Common specification

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB)/100 Square Foot
Inch MM Inch MM
1x1 .080 2.03 .920 23.37 84.6 41.1
2X2 .063 1.60 .437 11.10 76.4 51.2
3X3 .054 1.37 .279 7.09 70.1 56.7
4X4 .063 1.60 .187 4.75 56.0 104.8
4X4 .047 1.19 .203 5.16 65.9 57.6
5X5 .041 1.04 .159 4.04 63.2 54.9
6X6 .035 .89 .132 3.35 62.7 48.1
8X8 .028 .71 .097 2.46 60.2 41.1
10X10 .025 .64 .075 1.91 56.3 41.2
10X10 .020 .51 .080 2.03 64.0 26.1
12X12 .023 .584 .060 1.52 51.8 42.2
12X12 .020 .508 .063 1.60 57.2 31.6
14X14 .023 .584 .048 1.22 45.2 49.8
14X14 .020 .508 .051 1.30 51.0 37.2
16X16 .018 .457 .0445 1.13 50.7 34.5
18X18 .017 .432 .0386 .98 48.3 34.8
20X20 .020 .508 .0300 .76 36.0 55.2
20X20 .016 .406 .0340 .86 46.2 34.4
24X24 .014 .356 .0277 .70 44.2 31.8
30X30 .013 .330 .0203 .52 37.1 34.8
30X30 .012 .305 .0213 .54 40.8 29.4
30X30 .009 .229 .0243 .62 53.1 16.1
35X35 .011 .279 .0176 .45 37.9 29.0
40X40 .010 .254 .0150 .38 36.0 27.6
50X50 .009 .229 .0110 .28 30.3 28.4
50X50 .008 .203 .0120 .31 36.0 22.1
60X60 .0075 .191 .0092 .23 30.5 23.7
60X60 .007 .178 .0097 .25 33.9 20.4
70X70 .0065 .165 .0078 .20 29.8 20.8
80X80 .0065 .165 .0060 .15 23.0 23.2
80X80 .0055 .140 .0070 .18 31.4 16.9
90X90 .005 .127 .0061 .16 30.1 15.8
100X100 .0045 .114 .0055 .14 30.3 14.2
100X100 .004 .102 .0060 .15 36.0 11.0
100X100 .0035 .089 .0065 .17 42.3 8.3
110X110 .0040 .1016 .0051 .1295 30.7 12.4
120X120 .0037 .0940 .0064 .1168 30.7 11.6
150X150 .0026 .0660 .0041 .1041 37.4 7.1
160X160 .0025 .0635 .0038 .0965 36.4 5.94
180X180 .0023 .0584 .0033 .0838 34.7 6.7
200X200 .0021 .0533 .0029 .0737 33.6 6.2
250X250 .0016 .0406 .0024 .0610 36.0 4.4
270X270 .0016 .0406 .0021 .0533 32.2 4.7
300X300 .0051 .0381 .0018 .0457 29.7 3.04
325X325 .0014 .0356 .0017 .0432 30.0 4.40
400X400 .0010 .0254 .0015 .370 36.0 3.3
500X500 .0010 .0254 .0010 .0254 25.0 3.8
635X635 .0008 .0203 .0008 .0203 25.0 2.63

Characteristics

  • Corrosion resistance.
  • Anti-acid and alkali resistance
  • Anti-high temperture.
  • Good filter performance.
  • Long using life

Application

Extensively used in mining,chemial industury,food industury and pharamaceutial industury.

  • In acid, alkali environment conditions sieving and filtering.
  • Petroleum industry as mud mesh,.
  • Chemical fiber industry as screen mesh.
  • Plating industry as acid cleaning mesh.

Package

1. paper packing or plastic packing
2. carton packing
3. wooden packing
or acrroding to customer requirements.

FAQ
1. Ask: Are you Manufacturer or Trading Company?
Answer: We are the manufacturer, but we have the right of import and export.
2. Ask: What is your Payment Terms?
Answer: A. T/T, 30% in advance, the balance against the copy of B/L.
B. L/C, sight/irrevocable L/C.
3. Ask: How about the Delivery Time?
Answer: A: If have stock, the goods will delivery after advanced payment.
B: If no stock, 7-15 days after advanced payment.
C: if urgent, we will produce your goods first.
4. Ask: Do you provide Free Samples to test?
Answer: Yes, we provide the free samples with A4 size to check our quality.
5. Ask: What is your Trade Terms?
Answer: EXW, FOB, CNF, CIF, CIP, Door to Door.
6. Ask: What is your nearest Port?
Answer: Xingang, Tianjin. Also other port in China.
